Specifications:
| Brand | MSD |
| Category | Body |
| Color | Red |
| Emission Code | 5 |
| part type | Data Acquisition Module |
| Product Type | Power Grid |
| Sub Category | Control Modules |
| Warning | California Proposition 65 |
| Warranty | Manufacturer's Limited 1 Year Warranty |
| Brand | MSD |
| Category | Body |
| Color | Red |
| Emission Code | 5 |
| part type | Data Acquisition Module |
| Product Type | Power Grid |
| Sub Category | Control Modules |
| Warning | California Proposition 65 |
| Warranty | Manufacturer's Limited 1 Year Warranty |
| Description_INV | Power Grid Power Module |
| Description_DES | Power Grid Power Module - Red |
| Description_EXT | When connected to the Power Grid it will data log all the functions including Time from Launch, time or rpm of activation and deactivation. |
| Description_MKT | The MSD Power Module is a fully programmable, four stage solid state relay that can handle up to 20 Amps of current per channel. The Power Module eliminates the need for electromechanical relays, fuses and timers. |
| Description_MKT | Outputs can be controlled independently or simultaneously, giving great flexibility. It can be configured as a digital output (i.e. ON/OFF) or as a Pulse Width Modulated output (i.e. PWM) with user-programmable frequencies up to 10 Kilohertz. |
| Description_MKT | Outputs can use Time, RPM or temperature to control fans, pumps, nitrous systems and much more. |
| Description_MKT | A High Speed Data Logger can be used to record all functions when paired with the MSD PN 7730 Power Grid. |
| Description_FAB | Each channel is controlled via input wires or as programmed in the MSDView software |
| Description_FAB | Takes the place of 4 electromechanical relays |
| Description_FAB | Can be used stand alone or with MSD Power Grid PN 7730 |
| Description_FAB | Available in Red (P/N 7764) or Black (P/N 77643) |
| Description_FAB | 80 Amp capacity, 4 channels rated up to 20 Amps each |
| Description_FAB | Data Acquisition available when used with MSD Power Grid |
| Description_FAB | Built-in overcurrent protection, no fuses needed |
| Description_FAB | Trigger signals can include power, ground, temperature, or time |
